BRONZE BALL VALVE (THREADED)
SPECIFICATION
Presure
Rating:
PN20
Working
Medium:
Water,
Oil,
Steam,
Gas
Working
Tempurature:
T
≤170°C
Connection:
BSPT/NPT
Information
PRODUCT DETAIL
| Item | Material |
| Body | Bronze |
| Gasket | PTFE |
| Seat | PTFE |
| Ball | Brass + Chrome Plated |
| Stem | Brass |
| Packing | PTFE |
| Gland nut | Brass |
| Lever + Cover | Steel (Chrome plated) + PVC |
| Lever nut | Stainless steel |
Dimension
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 |
| INCH | 1/2 | 3/4 | 1 | 1.1/4 | 1.1/2 | 2 | 2.1/2 | 3 | 4 |
| d | 14 | 19 | 24 | 31 | 38 | 49 | 49 | 73 | 90 |
| L | 53 | 61 | 71 | 92 | 92 | 114 | 114 | 152 | 180 |
| H | 44 | 51 | 55 | 70 | 70 | 83 | 83 | 132 | 150 |
| D | 95 | 110 | 110 | 140 | 140 | 160 | 160 | 270 | 280 |
